Steel Bar Bending Machine

Working disk diameter ： 300mm/340mm/340mm/380mm

Motor Power ： 3kw/4kw/3kw/4kw

Weight ： 220kg/290kg/241kg/320kg

Class III rebar ： ≤Φ28mm/≤Φ32mm/≤Φ32mm/≤Φ36mm

Dimension ： 88*76*79cm/85*83*83cm/87*76*81cm/85*83*83cm

Send Email Chat Now 0086-17719865102

Share with:

Products

Concrete Mixer

JZC/JZM Portable Concrete Mixer

YJS Twin-shaft Concrete Mixer

Concrete Batching Plant

Bucket Type Concrete Batching Pl...

Belt Type Concrete Batching Plan...

Mobile Concrete Batching Plant

HZS25 Concrete Batching Plant

HZS50 Concrete Batching Plant

HZS75 Concrete Batching Plant

HZS90 Concrete Batching Plant

HZS120 Concrete Batch Plant

Concrete Pump

HBT Motor Driven Concrete Traile...

DHBT Diesel Engine Concrete Trai...

Concrete Mixer with Pump

JBT Electric Concrete Mixer With...

DJBT Diesel Engine Concrete Mixe...

Concrete Vibrator

MV Series Electrical Motor Vibra...

ZF/ZW Series External Concrete V...

ZN Series Inserted Concrete Vibr...

Steel Bar Processing Machine

Steel Bar Bending Machine

Steel Bar Cutting Machine

Steel Bar Straightening Machine

Email: sales@cndasion.com

PRODUCTS SEARCH

Quickly find DASION product

Product Parameter

Product Features

Parameters of Steel Bar Bending Machine

Item	Bending Range		Working disk diameter	Motor Power	Weight	Dimension
Item	Ordinary carbon steel	Class III rebar	Working disk diameter	Motor Power	Weight	Dimension
GW40	≤Φ30 mm	≤Φ28mm	300mm	3kw	220kg	887679cm
GW45A	≤Φ40 mm	≤Φ32 mm	340mm	4kw	290kg	858383cm
GW45B	≤Φ40 mm	≤Φ32 mm	340mm	3kw	241kg	877681cm
GW50	≤Φ50 mm	≤Φ36 mm	380mm	4kw	320kg	858383cm

Brief Introduction of Steel Bar Bending Machine:

Steel bar bending machine is suitable for various of geometric shapes that are required for the processing of various ordinary carbon steel and rebar in construction engineering.
The steel bar bending machine has the features of simple structure, reliable operation and sensitive operation. By using this machine, the rebar can be bent into various shapes required for buildings, bridges and various of construction projects.
